Abstract

Recently, cyber-physical system is widely used for smart system control in various fields. Various functions of the cyber-physical system must overcome the limited hardware resources constraint of an embedded system. In addition, the data required from the industrial cyber-physical system are critical; therefore, a highly secure encryption technique is required. However, security and computational throughput are incompatible with each other in the cryptographic technique; therefore, the industrial cyber-physical system needs to adopt a highly efficient and secure encryption technique considering the limited available resources. This study applies the m-folding method to the highly secure elliptic curve algorithm to improve efficiency and proposes the cryptosystem optimized for the resource-constrained industrial cyber-physical system. The proposed m-folding method–based elliptic curve encryption showed 50% faster encryption than the existing methods.

Keywords

Cryptography elliptic curve cyber-physical system m-folding security

Introduction

Currently, cyber-physical system^1–7 that has a wide range of application in industries such as factory, farm, veterinary, transportation, aviation, health care, and chemistry plays an important role in constructing an interaction system between cyber and physical elements. However, several security aspects should be carefully examined to successfully combine cyber-physical systems with various technologies. Current networks of energy grids, water supply, logistics, transportation, and so on comprise structures that are vulnerable to external malicious attacks. Data in the industrial cyber-physical system are usually critical, and they must be protected.

The cyber-physical system is based on an embedded system; therefore, it is necessary to consider the limited system resources in such a system. In addition, the encryption and decryption times are crucial because a low delay in control and response is required in cyber-physical system. In other words, the functions of the cyber-physical system should be designed based on algorithms with low computational complexity and high efficiency of resources. Generally, when the key length of the asymmetric key system increases, the encryption efficiency decreases due to the increased CPU time or memory requirements while implementing a cryptographic system. The amount of data to be sent and received also increases, thereby requiring more bandwidth for communication.^8–10 Therefore, existing cryptosystems such as Rivest–Shamir–Adleman (RSA)¹¹ or homomorphic encryption¹² are difficult to deploy in the cyber-physical system environment due to the large key size of the encrypted data.

Elliptic curve cryptosystem^13–16 is a cryptographic system that uses the computational complexity of the discrete logarithm problem on elliptic curves. It is an asymmetric key-based cryptosystem that has gained popularity in recent years due to the advantage of having a similar degree of safety with shorter key lengths compared to the conventional asymmetric key-based cryptosystem. Especially, security of the elliptic curve cryptosystem increases almost exponentially with the increase in the key length, and it has a considerable advantage in terms of rate of increase in the key length. This is a result of long-term technological advances compared to the existing asymmetric key cryptographic system with a quasi-index function. For example, the RSA cryptosystem must use approximately 15,000 bits of composite number to provide security similar to the elliptic curve cryptosystem of approximately 512 bits.¹¹

This study proposes the m-folding method–based elliptic curve cryptosystem for the industrial cyber-physical system. M-folding improves the scalar multiplication operation in elliptic curve cryptosystem by representing the number of multiplication count of a point as a bit string and further dividing it into arbitrary length. The elliptic curve cryptosystem architecture based on the m-folding method for the industrial cyber-physical system is also proposed in this study. Performance evaluation shows that the proposed method shows 50% faster encryption than the existing methods.

The rest of the article is organized as follows. Section “Related work” describes the related work and section “M-folding method-based elliptic curve encryption technique” describes the elliptic curve–based cryptosystem suitable for the industrial cyber-physical system. The performance evaluation results of the proposed method are presented in section “Performance evaluation.” Finally, section “Conclusion and future work” presents our conclusion and suggests future work.

Related work

Cyber-physical system

The cyber-physical systems^1–7 are the next-generation network-based distributed control systems that combine physical systems having sensors and actuators with computing elements that control them. The advances in the cyber-physical system technology are a key factor in making life more convenient and efficient; however, the risk and vulnerability in terms of safety have increased. Cyber terrorism is no longer limited to information security in virtual spaces such as computers or Internet servers but is capable of attacking the actual control system, which is a critical issue that could directly threaten our lives and shake the foundations of nations. An example of the first attack on control systems is the Stuxnet virus¹⁷ discovered in Iran in 2010. Cyber-attacks on various daily life or critical infrastructure have been reported since then. Therefore, the study of safety and security of cyber-physical systems has become more urgent and important than anything else.

A low delay in control and sensing is necessary in the cyber-physical system; therefore, the encryption and decryption times are crucial in such systems. The functions of the cyber-physical system should be designed based on algorithms with low computational complexity and memory usage. Symmetric key algorithms must use the same encryption key between the receiver and the sender and deliver the encryption key. It is not applicable for the cyber-physical system because a large number of devices need to communicate in order to share the same encryption/decryption key. Public key systems such as RSA and elliptic curve cryptosystem were designed to overcome the aforementioned limitations. The elliptic curve cryptosystem is more suitable in the cyber-physical system scenario due to its smaller key size. When the key length of the public key system increases, the number of computations and memory usage also increases with the increased size of the encryption data. Therefore, existing cryptosystems such as RSA¹¹ and homomorphic encryption¹² are difficult to deploy in the cyber-physical system environment.

Elliptic curve cryptography is gaining popularity in the field of cyber-physical system security due to its public key scheme and smaller key size compared to existing asymmetric key-based cryptosystem. Elliptic curve cryptography has several applications in the cyber-physical systems such as medical cyber-physical system encryption,¹⁸ wireless sensor network infrastructure,¹⁹ and key agreement in the smart grid.²⁰ However, none of these applications considered improving the encryption and decryption scheme for elliptic curve cryptography deployed in the cyber-physical system environment.

Elliptic curve cryptography

Elliptic curve cryptography^8,9 is a cubic equation with two variables. The general elliptic curve equation is given by equation (1)

$y^{2} + b_{1} xy + b_{2} y = x^{3} + a_{1} x^{2} + a_{2} x + a_{3}$ (1)

Elliptic curve in real number space uses an elliptical curve in a special category such as equation (2)

$y^{2} = x^{3} + ax + b$ (2)

In an elliptic curve encryption technique, if $4 a^{3} + 27 b^{2} \neq 0$ , the curve is a nonsingular elliptic curve, or it represents a unique elliptical curve. A regular elliptical curve cannot have three different roots. Figure 1 shows an example of finding another point on a curve when two points on a curve are added in an elliptic curve.

Figure 1.

Three cases of elliptic curve.

In case of $P \neq Q$

$\begin{matrix} λ = \frac{y_{2} - y_{1}}{x_{2} - x_{1}} \\ x_{3} = λ^{2} - x_{1} - x_{2} \\ y_{3} = λ (x_{1} - x_{3}) - y_{1} \end{matrix}$ (3)

In case of $P = Q$

$\begin{matrix} λ = \frac{3 x_{1}^{2} + a}{2 y_{1}} \\ x_{3} = λ^{2} - x_{1} - x_{2} \\ y_{3} = λ (x_{1} - x_{3}) - y_{1} \end{matrix}$ (4)

In the case when $P = - P$ , the straight line connecting these two points does not intersect at the other point of the elliptic curve; therefore, the other point is defined as O, and it becomes an identity element for addition.

Fast scalar multiplications for elliptic curve cryptography

The main computation performed by the elliptic curve–based encryption technique is the computation: $d * P$ that multiplies the point P by d. In other words, point P is added d times. As the addition in elliptic curve shows, multiplication, addition, and inverse calculations must be performed. Furthermore, scalar multiplication that can be performed by repetition of the aforementioned computations requires considerable computational time, which is an important factor determining the performance of the entire cryptosystem. Research works^21–28 have been conducted on algorithms that can speed up the d iterative addition operations of point P in large numbers that usually exceed 160 bits. Therefore, to achieve high efficiency of the cyber-physical system with limited resources, the performance of scalar multiplication should be improved. First, we discuss the existing scalar multiplication algorithm and then propose a new algorithm that performs better than the existing one.

Binary method

The binary method^23,24 is a technique of expressing d in binary numbers by reading from the most significant bits sequentially and processing according to the following conditions:

If the bit is 0, perform point doubling.

If the bit is 1, perform point addition with P after point doubling.

The binary method represented by a specific algorithm is shown in Figure 2. For example, as shown in Figure 3, to calculate 186P, 186 is expressed as binary number 10111010 and processed according to the algorithm in Figure 2. However, simply adding Pd times increases the number of addition operations and computation time.

Figure 2.

Algorithm of binary method.

Figure 3.

Computation process of binary method.

M-ary method

The m-ary method²⁵ is a computation technique for reducing the number of digits by generalizing what is expressed as binary number in the binary method. The format of expression used by this method is $(d_{L - 1}, d_{L - 2}, d_{L - 3}, \dots, d_{0})$ , which is faster by a small degree than the binary method. In the m-ary method, d is expressed as an m-ary number having L figures. $iP (i = 1, 2, \dots, m - 1)$ is calculated in advance, and then the value of $dP$ is calculated by performing point addition m times and $iP$ times from $d_{L - 1}$ to $d_{0}$ , respectively.

The m-ary method represented by a specific algorithm is shown in Figure 4. For example, to calculate 186P, 186 is expressed as tetramal 2322 and processed according to Figure 5. Storing even numbers such as 2P, 4P, and 6P in the m-ary method can waste memory. For example, 2P is two times P, 4P is four times P, and 6P is two times 3P. As shown by the algorithm in Figure 4, point doubling is performed on each loop basically and with only P or 3P. 2P, 4P, and 6P can be calculated with the same number of calculations. Therefore, information from 2P, 4P, and 6P being unnecessary information can waste memory.

Figure 4.

Algorithm of m-ary method.

Figure 5.

Computation process of m-ary method.

Window method

In the window method,²⁶ when d is expressed in binary form, a set of bits less than a certain length, w, with start and end as 1 is called windows. It is calculated in advance and processed in a manner similar to the m-ary method. The window method is represented by a specific algorithm shown in Figure 6. For example, to calculate 186P, 186 is expressed as binary 10111010 as shown in Figure 7 and processed according to the above algorithm.

Figure 6.

Algorithm of window method.

Figure 7.

Computation process of window method.

The window method stores only odd multiples such as P, 3P, and 5P; therefore, it does not encounter the memory space problem of the m-ary method. Consequently, it is possible to store a higher multiple of P values using the same memory space when compared to the m-ary method. However, the memory may be wasted in other ways, for example, if the window size is three, the look-up table stores 3P, 5P, and 7P; however, there may actually exist values referenced less than two times. In addition, as shown in Figure 7, the value 7P is not used, which can result in memory wastage.

Scalar-folding method

In the scalar-folding method,²⁷d is expressed as a binary number. Furthermore, its bit string $(d_{L - 1}, d_{L - 2}, d_{L - 3}, \dots, d_{0})$ is divided into $(d_{L - 1}, \dots, d_{L / 2})$ and $(d_{L / 2 - 1}, \dots, d_{0})$ . If L is an odd number, only the upper bits except the lower 1 bit are considered and the lower 1 bit is calculated at the end. The value of the first start bit of the upper part, $2^{L / 2}$ , is calculated and stored in the look-up table. Furthermore, to calculate the upper and lower parts at the same time, the value of $dP$ is calculated using $\sum_{i = 0}^{(L / 2) - 1} 2^{i} ((d_{i + L / 2} 2^{L / 2} P) + d_{i} P))$ . For example, to calculate 186P, 186 is expressed as binary 10111010 and processed according to the algorithm, as shown in Figure 8.

Figure 8.

Algorithm of scalar-folding method.

Analysis of existing methods

The existing methods solely focus on decreasing the number of computations in a general scenario. In the cyber-physical system environment, where a large number of devices are deployed and authentication keys do not change frequently with p, a scheme that can take advantage of pre-computed look-up table can greatly improve the real-time encryption/decryption performance of the elliptic curve–based cryptosystem. We propose the computation method that can flexibly fold a bit string in arbitrary size and utilize a pre-computed look-up table.

M-folding method–based elliptic curve encryption technique

M-folding method

This study proposes the m-folding method. It divides a bit string into m parts and calculates all the parts simultaneously. It is an extension of the scalar-folding method that divides the existing bit string into two parts. First, d is expressed as binary number and its bit string $(d_{L - 1}, d_{L - 2}, d_{L - 3}, \dots, d_{0})$ is divided into $(d_{L - 1}, \dots, d_{L - 1 - L / m})$ , $(d_{L - 2 - L / m}, \dots, d_{L - 2 - 2 L / m})$ , and so on. If L is not divisible by m, the lower part $(L \mod m)$ is calculated later, and the starting bit of each part is calculated and stored in the look-up table. The value of $dP$ is then calculated using $\sum_{i = 0}^{L / 2 - 1} 2^{i} ((d_{i + L / 2} 2^{L / 2} P) + d_{i} P))$ to calculate the upper and lower parts at the same time. For example, to calculate 186P, 186 is expressed as binary 10111010 as shown in Figure 9 and processed according to Figure 10.

Figure 9.

Algorithm of proposed method.

Figure 10.

Computation process of proposed method.

Elliptic curve–based cryptosystem architecture

This study designed the m-folding method–based elliptic curve cryptosystem architecture for the industrial cyber-physical system. Figure 11 shows the proposed architecture. M-folding method–based elliptic curve cryptosystem comprises an encryption management module that performs encryption and decryption, an elliptic curve management module that executes an m-folding method–based elliptic curve encryption algorithm, and a key management module that manages the encryption keys.

Figure 11.

Elliptic curve–based cryptosystem architecture.

Encryption management

This module encrypts the messages generated by the message generator in the message module through the encryption process or receives the encrypted messages from the network and sends the messages decrypted by the decryption process to the message parser in the message module. The encryption and decryption algorithm simulates the ElGamal cryptosystem among asymmetric key-based encryption techniques. The encryption and decryption processes are given by equations (5) and (6). First, a point P corresponding to the plain text is selected on the curve. Furthermore, two points to be used as ciphertexts are calculated using equations (5) and (6) where r is an arbitrary integer; $e_{1}$ and $e_{2}$ are recipient’s public key to receive the encrypted message at the point on the elliptic curve

$C_{1} = r \times e_{1}$ (5)

$C_{2} = P + r \times e_{2}$ (6)

The decoding calculates P using equation (7), where d is any integer

$P = C_{2} - (d \times C_{1})$ (7)

Stability of the elliptic curve²⁸ is based on the computational complexity of solving the elliptic curve logarithm problem. For example, if an intruder has obtained $C_{1}$ and $e_{1}$ over the network, they can find r using equation $C_{1} = r \times e_{1}$ . However, the intruder cannot calculate plain text P in $C_{2} = P + r \times e_{2}$ easily because it is very difficult to calculate r as an elliptic curve logarithm problem.

Elliptic curve management

This study uses the elliptic curve equation recommended by the Korean certificate–based digital signature algorithm using elliptic curve (EC_KCDSA).⁴ The equation generator generates and manages finite field variables that are necessary to define the elliptic curve equation. EC-KCDSA recommends two types of elliptic curves to be used for encryption: arbitrary curve given by equation (8) and the Koblitz curve given by equation (9)

$y^{2} = x^{3} - 3 x + b$ (8)

$y^{2} = x^{3} + b$ (9)

The elliptic curve equation in this study is based on the Koblitz elliptic curve equation because it can be calculated efficiently and can consequently ensure faster encryption. The elliptic curve arithmetic module defines the operations required for the encryption module, for example, finding points on an elliptic curve or addition operation between two points.

Key management

The private/public key generator generates public and private keys for encryption and decryption based on elliptic curve. The public key selects an arbitrary point $e_{1}$ on an elliptic curve equation and an elliptic curve. Then, an arbitrary integer d is selected and $e_{2}$ is calculated as $e_{2} = d \times e_{1}$ . Here, $e_{1}$ , $e_{2}$ , and the elliptic curve are declared as its own public key, and d being a private key is not disclosed. The session key list module manages the sessions between nodes, stores the keys used for each session in a table, and manages the sessions and related keys through key distribution and deletion.

Performance evaluation

During performance evaluation, performance of the m-folding method was compared with existing scalar multiplication algorithms in the following three conditions: (1) when look-up tables are not used, (2) when look-up tables are used, and (3) when pre-computed look-up tables are used. When the look-up table is calculated in advance, it is not created each time the algorithm is executed; however, the created table is stored at a known location and reused. The performance evaluation compares the processing speed of $d * P$ using a constant d that is 160 bits long and point P on an elliptic curve. While using look-up tables, cases such as m-ary, window, folding, and m-folding need to be considered due to the characteristics of the algorithm; however, scalar-folding is excluded from the performance comparison because scalar-folding is the case when the value m is 2 in m-folding.

Case when look-up table is not used

Figure 12 shows the performance result without the look-up table. Each algorithm showed a processing speed between 138 and 141 ms, thereby showing no significant difference in performance.

Figure 12.

Case when look-up table is not used.

Case when look-up table is used

Figure 13 shows the performance when the look-up table is used. The window technique showed better performance when the look-up table had larger memory. As the size of the look-up table increases, the performance of m-ary method increases. However, after a certain level, the performance decreases because when a binary number is converted to the given base, the larger the value of m, the larger are the required memory and conversion time. In the proposed m-folding technique, the values stored in the look-up tables are $P * 2^{n}$ that do not affect the performance significantly because they are necessary for the scalar multiplication.

Figure 13.

Case when look-up table is used.

Case when look-up table is created in advance and recycled

The performance results in Figure 14 show that when the look-up table is pre-computed, the processing speed increases when the additional storage size increases because the time to re-create the tables is saved. Compared to the window method, the m-ary method showed slightly better performance. M-folding method showed better performance than other algorithms when the storage space was two or more, and the processing speed was approximately two times faster when the storage space was four or more. On the contrary, the rate of improvement of the processing speed relative to storage size gradually decreased because the bit string of d is divided into a number 2^m; therefore, as the value of m increases, the rate of increase in value $2^{L - 1 - L / m} * P$ stored in the look-up table exponentially decreases.

Figure 14.

Case when look-up table is pre-computed and recycled.

As a result, the proposed m-folding method shows good performance while using a pre-stored look-up table. Using pre-stored look-up table is suitable in an environment where the value of p does not change much. The cryptosystem used in this study does not change the value of p; therefore, the authentication key of other controllers can be used for the look-up table in advance by the proposed m-folding method to be used later.

Conclusion and future work

This study analyzed the elliptic curve algorithm that is more efficient than the asymmetric-based encryption technique and designed the encryption technique with improved performance by applying the m-folding method that is more efficient than the existing scalar multiplication algorithm. This technique can mitigate the resource constraint problem; therefore, we used it to design the m-folding method–based elliptic curve cryptosystem structure suitable for the industrial cyber-physical system. However, the performance evaluation results showed excellent performance only when the look-up table is pre-computed and recycled.

In the future, it is necessary to research a cryptosystem that can improve the security of the industrial cyber-physical system using an encryption technique with high security and efficiency such as elliptic curve algorithm or comprehensively researching a high-performance technique regardless of a look-up table.
